TFT Panel Type a-Si TFT-LCD 27Inch 1920x1080 FHD LCD Screen for Digital Signage ATM VTM e-shelf POS Display Modules

Type : TFT

Display Size : 27inch

Supplier Type : Original Brand

Place of Origin : China

Brand Name : AUO

Panel Type : a-Si TFT-LCD, LCM

Resolution : 1920(RGB)x1080, FHD 81PPI

Module Outsize(mm) : 613.6(H)x356.85(V) x10.5(D) mm

Viewing Angle : 89/89/89/89 (Typ.)(CR≥10)

Brightness : 300cd/m2

Interface : LVDS (2 ch, 8-bit) , 30 pins Connector

Touch Screen : Without

Application : Digital Signage ATM VTM e-shelf POS

MPQ : 10pcs

Warranty : 12 Months

Price : $89/pieces 1-99 pieces

Contact Now

TFT Panel Type a-Si TFT-LCD 27Inch 1920x1080 FHD LCD Screen for Digital Signage ATM VTM e-shelf POS Display Modules

Products Description

Panel Model	P270HVN02.0	Panel Brand	AUO
Size (inch )	27inch	Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 81PPI	Pixel Format	RGB Vertical Stripe
Module Outsize(mm)	613.6 × 356.85 × 10.5 (H×V×D)	Display Mode	VA, Normally Black, Transmissive
LCD Active area(mm)	597.6(W)×336.15(H) mm	Response Time	7/5 (Typ.)(Tr/Td) ms
Display Colors	16.7M 72% NTSC	Light Source	15S4P WLED , 40K hours , No Driver
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Touch Screen	Without
Brightness	300 cd/m² (Typ.)	Power Supply	5.0V (Typ.)
Contrast Ratio	3000:1 (Typ.) (TM)	Used for	Digital Signage
Frame Ratio	60Hz	Enviroment	Storage Temp.: -20~ 60 °C
Frame Ratio	60Hz	Enviroment		Operating Temp.: -0 ~ 50°C
LCM Interface Type	LVDS (2 ch, 8-bit) , 30 pins Connector	FPC connector	P-two, AL230F-A0G1D-P, Pitch 1.0mm

Details Images

Company Profile

FAQ

Q1. What is your lead time? A: Stock: 5-15 days in general. No stock: 15-30 days after samples confirmed. Or please contact us by email for specific lead time base on your order quantities. Q2. How does your factory do regarding quality control? A: Quality is priority. We always attach great importance to quality control from the very beginning to the end: 1) All raw material we used are non-toxic, environmental-friendly; 2) Skillful workers pay great attention to each details in handling the producing and packing processes; 3) We have a professional QA/QC team to ensure the quality. Q3. Do you accept OEM or ODM order? A: Yes, we accept both OEM and ODM for customers. Q4. What are your terms of delivery? A: We can accept EXW, FOB, CIF, etc. You can choose one which is the most convenient for you. Q5. What is the payment way? A: TT, Pay Later, West Union,Online Bank Payment. Should you have other questions, please let us know. We’ll add answers here for your further references. Thank you.
